Product Description
The StompBoxParts 3PDT Pro footswitch! A modern standard for true bypass switching with an LED. A superior quality option for hand builds, and the highest temp plastic and epoxy we could find for the abuses of large-volume manufacturering. Comes with two nuts, lock washer, and metal flat washer.
-Ultra-High Temperature Durability - They can handle intense heat. We dipped these half way up the plastic casing in our wave solder bed for 15 seconds with no deformation and perfect continuity tests. Lugs stay firmly in place even under extreme heat.
-Choice of Activation Force - ~1kg (35oz) for the black model, ~3kg (100oz) click for the red.
-PCB Standoff Corners - Keeps PCB level and at an appropriate height away from the casing.
Mounts in a 12mm or 11/32" hole.
Termination Style: Solder Lug
Rating: DC 9V, 1A
Contact Resistance: < 30mΩ
Insulation Resistance: DC 500V >100MΩ
Dielectric Strength: 500V RMS @SEA LEVEL.
Mechanical Life :30,000 MAKE-AND-BREAK CYCLES
RoHS & Lead Free
Solder lug, triple pole double throw. Latching.
