Product Description
16mm dual gang potentiometer.
Short PCB pin terminals.
1/4" (6.35mm) round shaft.
Specs:
Tolerance: <10% typical, 20% max
Insulation wafer: Fiberglass (extremly strong compared to orange phenolic resin wafer)
Insulation resistance 100MΩ min at 500vDC
Power: .1w B taper, .05w A/C/W
Rotation life: 10,000 cycles minimum
Rotation angle: 300° (+/- 5°)
Rotation torque: 50 gf·cm (+/- 20 gf·cm)
RoHS Compliant
A=Audio/Logarithmic. 15% resistance @ 50% travel.
B=Linear. 50% resistance @ 50% travel.
C=Reverse Logarithmic. 85% resistance @ 50% travel.
D=Steep Audio/Logarithmic. 10% resistance @ 50% travel.
W=Logarithmic first half, reverse logarithmic last half.
